9.7 inch_G097-5107650651-L30PND(30P LVDS,1024*768,650nits,IPS, -20~80)
9.7 inch_G097-5107650651-L30PND(30P LVDS,1024*768,650nits,IPS, -20~80)
  • 9.7 inch_G097-5107650651-L30PND(30P LVDS,1024*768,650nits,IPS, -20~80)
  • 9.7 inch_G097-5107650651-L30PND(30P LVDS,1024*768,650nits,IPS, -20~80)
9.7 inch_G097-5107650651-L30PND(30P LVDS,1024*768,650nits,IPS, -20~80)

1、LCD Size:9.7 inch


2、Resolution:1024*768


3、Active area(mm): 196.60*147.45


4、Luminance:650cd/m2


5、Contrast ratio:900:1


6、LCM Size(mm):209.40*163.40*5.0


7、Operation Temperature:-20~80


8、Storage Temperature:-30~80


9、Interface:30P LVDS


10、View angle :IPS


11、LED life time(Typ.) :30000 H
