9.7 inch_G097-5107650651-L30PND(30P LVDS,1024*768,650nits,IPS, -20~80)

1、LCD Size：9.7 inch

2、Resolution：1024*768

3、Active area(mm): 196.60*147.45

4、Luminance：650cd/m2

5、Contrast ratio：900：1

6、LCM Size(mm)：209.40*163.40*5.0

7、Operation Temperature：-20~80

8、Storage Temperature：-30~80

9、Interface：30P LVDS

10、View angle ：IPS

11、LED life time(Typ.) ：30000 H
